A precision 4 way imperial dial caliper in high grade stainless steel for values in the range 0-6″ covering internal, external, height and step. Accuracy assured for a broad range of industrial and automotive calculations. Features
Smooth operating rack and pinion transfers slider movements to dial (Calibrations 0.001″)
Dial zero adjustment and lock.
Thumbwheel for fine adjustment.
Locking screw f
A precision 4 way metric dial caliper in high grade stainless steel for values in the range 0-150mm covering internal, external, height and step. Accuracy assured for a broad range of industrial and automotive calculations. Features
Smooth operating rack and pinion transfers slider movements to dial (Calibrations 0.02mm)
Dial zero adjustment and lock.
Thumbwheel for fine adjustment.
Locking screw
square, centre, and protractor heads with (12″) stainless steel rule Features
Measuring heads lock onto the rule for precise square, centreing and angular alignment
Square head sets rule to 90° or 45° to edge, includes spirit level and 45 mm long steel scriber
Centre head locates centres accurately on round sections
Protractor head 0-180° scale (graduated every 1 degree) measures angles to an edge
A precision 0-10 mm plunger type indicator with adjustable dial and knurled bezel for zero setting. Features
Large clear dial with integral rev. counter
Built in rear mounting lug.
Reads graduations 0.01 mm over 10 mm travel
Hardened stainless steel rack and sensitive pivot bearings for accuracy.
A precision 0 – 0.8 mm lever type indicator with low inertia jewelled bearings and tungsten carbide contact point for high sensitivity, repeatability, and accuracy. Features
Adjustable bezel for zero setting.
Auto reversible contact point adjusts through 240°
Supplied with 6 mm & 8 mm diameter dovetail attachments.
Reads 0-40-0° – in 0.07mm graduations
For precise measuring and scribing this vernier height gauge ensures high accuracy readings within the range 0-12″ (0-300mm). Manufactured from the finest quality stainless steel hardened and ground as appropriate. Features
Dual calibration with gradations to 0.02mm / 0.001″.
Fine adjustable facility.
Lockable measuring slide with magnifier.
Adjustable zero / reference scale setting.
Tungsten carb
A comprehensive 52 piece fixing kit secured to a slotted worktable prior to drilling or milling. For use with the CMD 1225 miller driller. Features
Includes wall mounting steel rack for neat & easy storage.
A simple device for bending mild steel sheet at various angles, up to 90°. Once mounted into a suitable bench vice, full manual control enables consistently accurate results to be easily obtained. Ideal for general metal fabrication. Features
Maximum sheet steel capacity 22 swg (0.71 mm)
Max. width Capacity 600 mm
Bench mounted
Ideal for DIY use, the CMFT220 multi-function tool is great for sawing, cutting, sanding, polishing and chiselling. 20,000 oscillations per minute and comes complete with a sanding pad, 3 sanding sheets, 2 cutting blades, scraper blade & a side handle for extra control. Features
20,000 strokes/min
Oscillating action
3°orbit angle
Quick & easy accessory change
Includes sanding pad, 3 sanding sheets
This vice is ideal for both mechanics and engineers and benefits from a cast iron body for added reliability, and a swivel base with rotating jaws with a calibrated scale. This model also has a jaw opening of 101 x 102 x 57mm (Width x Opening x Depth) and is completed with an integrated anvil. Features
Cast iron body
Jaws (Width x Opening x Depth): 101x102x57mm
Integrated anvil
Weight: 9.4kg
This vice is ideal for both mechanics and engineers and benefits from a cast iron body for added reliability, and a swivel base with rotating jaws with a calibrated scale. This model also has a jaw opening of 126 x 130 x 70mm (Width x Opening x Depth) and is completed with an integrated anvil. Features
Cast iron body
Jaws (Width x Opening x Depth) : 126x130x70mm
Integrated anvil
Weight: 15.5kg
